Better Labeling Workflows for Pipe Networks with Label Genie

Published: 14 October 2020
on channel: CTC Software

393

Pipe Network labeling can be a tedious task. We often need different label styles depending on the part type. When you have 75+ parts in a drawing, that becomes a large task. With Label Genie from the CIM Project Suite, users can define label style mappings based on their parts list. When an entire network is to be labeled, each part and size will received the appropriate label.

Learning Objectives:
Define detailed label style mapping based on parts lists
Automatically insert unique labels for different types of parts
Label multiple drawings at once
