Esp8266 WiFi Module setup using Arduino Uno || ESP8266 Blynk || IoT Project || uElectroPro
Hi! In this video I will show you how to getting started with esp8266-01 WiFi module and make a simple LED light controlling project using Arduino, ESP8266 and Blynk App
00:37 Circuit Diagram
00:42 Remove Atmega328P
Remove Atmega328P Because we directly want to communicate with esp8266 through serial monitor(as USB to serial convertor), not from the atmega328p
00:55 Make connections (for esp8266 communication)
01:18 Check Arduino Board and port
01:30 Open Serial monitor (set baud rate and Both NL & CR)
By reconnecting the GND wire of Esp8266, it will print the "ready" on Serial monitor that means now it is ready for AT commands. First I write some AT commands to test esp8266 and then changed the baud rate of the ESP8266.
02:04 Change Baud rate of esp8266, write AT+UART_DEF=9600,8,1,0,0
03:07 Download the Blynk App and Libraries
06:21 Make connections for final setup
07:26 Setup the Blynk App
09:19 Source code
10:50 Make some changes in code and upload
13:15 Done!
Note: If you are getting esp not responding then first check the TX and RX connections and make sure wires are not loose and broken. Second check the baud rate.
Code: https://drive.google.com/file/d/14B10...
Schematic for communicating with esp or changing the baud rate:
https://drive.google.com/open?id=1lEZ...
Schematic for final setup:
https://drive.google.com/open?id=1kEj...
Home Automation using ESP8266 : • ESP8266 Home Automation with Blynk |...
Subscribe our channel : / @uelectropro
Like us on Facebook: / electronic-projects-1570703653022589
I hope you Like this video. If so
don't forget to Subscribe and if you have any question related to this topic then feel free to comment
